• Patented systems for cleaning, disinfection and drying
  • Variable and selectable cleaning time and procedure
  • Unified cleaning system (cleaning, disinfection, washing, rinsing, drying)
  • High quality stainless steel construction
  • Quality assurance and certification



This state of the art Chemical Protection Suit Cleaning System provides for first quality comprehensive cleaning including disinfection and drying.

This leads to the best cleaning results of your equipment such as respiratory protection masks, breathing regulators or CPS of all types at low personnel costs.

  • Self-explanatory menu navigation, easy programme selection
  • Stainless steel (1.4301)
  • Fully automatic dosing with level control
  • Separate discharge of waste water possible
  • Constant ventilation of washing room
  • Side Channel Blower with heater for fast drying
  • Remote-access online maintenance possible

bsp bedienung



bsp twin



bsp innenraum



logo hohenstein gutachten

 log dekra untersuchung

 logo bsp system

 logo aktionsprodukte de



Customer video




Cleaning Module for Chemical
Protection Suit

(CPS) (Art. No. 74.50.11.00)

  • For fully automatic procedure of all
    cleaning processes for CPS
    (rinsing, cleaning, disinfection, drying)
  • Seawater resistant anodized aluminum
    frame for protective clothing which is
    air-steamed for optimal cleaning and
    prevention of wrinkles
bsp kalle




Cleaning Module for Respiratory
Protection Masks

(Art. No. 74.50.05.24)

  • For fully automatic procedure of all cleaning processes for up to 24 protection masks
    (rinsing, cleaning, disinfection, drying)
  • For different types of masks
  • Cleaning without mechanical stress through rotating and swinging movement of the baskets
  • Entirely stainless steel, also connectable to ceiling rail system
bsp maskenmodul24




Cleaning Module for
Breathing Regulators

(Art. No. 74.50.07.00)

  • For fully automatic procedure of all cleaning processes for up to 32 breathing regulators
    (rinsing, cleaning, disinfection, drying)
  • 4 rotating receptacles with 8 flexible
    cleaning spaces for breathing regulators
  • Entirely stainless steel, also connectable
    to ceiling rail system
bsp lamodul





Cleaning Module for
Compressed Air Breathing
Apparatuses

(Art. No. 74.50.06.00)

  • For fully automatic procedure of all cleaning processes for up to 6 compressed air breathing apparatuses simultaneously
    (rinsing, cleaning, disinfection, drying)
  • 2 vertical cleaning levels with 4
    motor-driven rotating washing frames
  • Including 6 compressed air bottles at 0.36 l each
  • Packing units for manometer and electric attachment parts
  • Entirely stainless steel, also connectable to ceiling rail system
bsp pamodul





Cleaning Combi-Module for
Respiratory Protection Masks
and Breathing Regulators

(Art. No. 74.50.05.02)

  • Fully automated procedure of all cleaning processes for up to 12 protection masks and 16 breathing regulators
    (rinsing, cleaning, disinfection, drying)
  • This alternative module is a perfect combination
    to the single version of masks and
    regulators offering maximum flexibility for
    a user that has low throughput
  • Cleaning without mechanical stress
    through rotating and swinging movement
    of the baskets
  • Built entirely from stainless steel and
    connectable to a ceiling rail system
bsp kombimodul





Cleaning Module for Helmets

(Art. No. 74.50.07.50)

  • For fully automatic procedure of all
    cleaning processes for up to 16 helmets simultaneously
    (rinsing, cleaning, disinfection, drying)
  • 1 motor-driven washing frame with one
    spray lance per level
  • Entirely stainless steel, also connectable
    to ceiling rail system
bsp helmmodul





Portable CPS Unit

(Art. No. 74.55.01.01)

  • For the storage and transportation
    of 2 Chemical Protection Suits
  • Hydraulic height adjustment
    via local foot pump
  • Entirely stainless steel
  • Transfer feature for ceiling rail system and
    for connection directly to CPS-Station
bsp teleskopwagen
